Programming with SPM
Page 39
Using SPM
Table 5. Board Types
Follow the steps below to assign modules.
Board Type Description
/65
4 loop-start line jacks with 4 touch-tone receivers
*/5
4 ground-start/loop-start line jacks with 4 touch-tone receivers
/6
8 loop-start line jacks
*/,'
8 ground-start/loop-start line jacks with Caller ID capability
available on the loop-start lines and 2 touch-tone receivers
*/6
8 ground-start/loop-start line jacks
/6$
4 loop-start line jacks and 8 ATL analog extension jacks
*/$
4 ground-start/loop-start line jacks and 8 ATL analog extension
jacks
*/0
4 ground-start/loop-start line jacks and 8 MLX extension jacks
(16 endpoints)
$7/
8 analog extension jacks
0/;
8 MLX-20L extension jacks (16 endpoints)
75237
12 tip/ring extension jacks with 2 touch-tone receivers or 008
OPT jacks
755
16 tip/ring extension jacks with 4 touch-tone receivers
','
8 DID trunk jacks with 2 touch-tone receivers
(0
4 E&M tie trunk jacks
'
1 DS1 jack (24 channels)
%5,
8 BRI trunk jacks (16 channels)
