IGA 320/23-LO Operating Manual Data format UPP (Universal Pyrometer Protocol)
•
29
7 Data format UPP (Universal Pyrometer
Protocol)
Via interface and suitable communication software or via Test function of the InfraWin
software commands can be exchanged directly with the pyrometer.
The data exchange occurs in ASCII format with the following transmission parameters:
The data format is: 8 data bits, 1 stop bit, even parity (8, 1, e).
The device responds to the entry of a command with: output (e.g. the measuring value) + CR
(Carriage Return, ASCII 13), to pure entry commands with ok + CR.
Every command starts with the 2-digit device address AA (e.g. "00"). This is followed by 2 small
command letters (e.g. "em" for level of emissivity
ε), finished with CR.
This is followed, if necessary for that command, by the ASCII parameter "X". If this parameter
"X" is omitted, then the device resets with the current parameter.
A ? after the small command letters answers with the respective settings (only at setting
commands, not at enquiry commands).
Example: Entry: “00em“ + <CR>
The emissivity setting (
ε) of the device with the address 00 is returned.
Answer: “0970“ + <CR> means Emissivity = 0.97 or 97.0%
Description
Command
Parameters
Reading
temperature
value:
AAms
Output: XXXXX (dec., in 1/10 °C or °F)
(77770 = Instrument’s temperature too high
88880 = temperature overflow)
Reading
temperature
value repeated:
AAmsXXX
XXX = 000...999 (XXX = number of measuring values)
Emissivity:
AAemXXXX
XXXX = (0100 ... 1000‰) (decimal)
Transmittance:
AAetXXXX
XXXX = (0100 ... 1000‰) (decimal)
Ambient
temperature
compensation:
AAutXXXX
XXXX = value of ambient temperature, 4-digit, hex
XXXX e.g. FFEC corresponds to -20 degrees
- 99
dez
= FF9D
hex
means: automatic, no manual
compensation
Exposure time t
90
:
AAezX
X = 0 ... 6 (decimal)
0 = intrinsic time constant of the device
1 = 0.01 s 3 = 0.25 s 5 = 3.00 s
2 = 0.05 s 4 = 1.00 s 6 = 10.00 s
Clear times of
the maximum
value storage:
AAlzX
X = 0 ... 9 (decimal)
0 = Maximum value storage off
1 = 0.01 s 4 = 1.00 s 7 = external deletion
2 = 0.05 s 5 = 5.00 s 8 = automatic deletion
3 = 0.25 s 6 = 25.00 s
External clearing:
AAlx
Clearing the max. value storage (only with lz = 7, external)
