IGA 320/23-LO Operating Manual Introduction
•
11
2.4 Dimensions
2.4.1 Instrument
2.4.2 Optics
Optical Head Type I (Fixed Adjusted)
Optical Head Type II (Fixed Adjusted)
Optical Head Type II (Focusable)
161.8
144.3
102
48
29
Ø
23.5
Ø
25
M25 x1.5
