Page #4 background imageLoading...
Page #4 background image
IGA 320/23-LO Operating Manual Introduction
9
2 Introduction
2.1 Appropriate use
The IGA 320/23-LO is a short wavelength temperature measuring instrument with fiber optics
and internal digital signal processing capabilities. This pyrometer is used for non-contact
temperature measurements on metals, ceramics, graphite, etc. with a temperature range
between 85 and 1200 °C.
For optimal match of the instrument to the application, two different optical heads are
available. The small dimensions of the optics allow easy integration into compact production
machines. The instrument is equipped with a fiber and an exchangeable optical head. The fiber
and optical head are unaffected by electromagnetic interferences (e.g. induction) and can be
used in high ambient temperatures up to 200 °C without additional cooling.
The LED targeting light enables precise alignment on the measurement object. It is
automatically active and can be used during measurement. In addition to the analog output, the
pyrometer is equipped with a digital RS485 interface, which enables secure data transmission to
a PC or a PLC over long distances.
The included InfraWin software enables graphical display and storage of measurement values,
as well as easy set-up of all instrument parameters.
2.2 Scope of delivery
Pyrometer IGA 320/23-LO, PC adjustment and evaluation software InfraWin”, inspection sheet,
manual. Fiber, one selectable optical head.
Note: A connection cable is not included with the instrument and has to be ordered
separately (see Chapter 8
, Reference numbers).
2.3 Technical data
Temperature ranges:
85 … 600 °C (MB 6)
100 ... 700 °C (MB 7)
150 … 1200 °C (MB 12)
Sub range:
Any range adjustable within the temperature range
minimum span 51 °C
Spectral range:
2 to 2.6 µm (main wavelength 2.3 µm)
IR detector:
Extended InGaAs
Optics:
Optical head Type I or Type II
Fiber Ø 0.6 mm (green fiber mark) for MB 6
Fiber Ø 0.4 mm (blue fiber mark) for MB 7
Fiber Ø 0.2 mm (red fiber mark) for MB 12
DIN connector electronics side SMA connector optics side
Power supply:
24 V DC (10 to 30 V DC), ripple must be less than 0.5 V
Power consumption:
Max. 1 W
Analog output:
0 to 20 mA or 4 to 20 mA (linear), switchable
Load:
0 to 500
Switch contact:
Opto relays; max. 50 V DC, 0.2 A; max. P
max
= 300 mW
