Lumens VC-A71P

26
Gain Limit
1. 9 dB
2. 12 dB
3. 15 dB
4. 18 dB
5. 21 dB
6. 24 dB
7. 27 dB
8. 30 dB
9. 33 dB
10. 36 dB
11. 39 dB
12. 42 dB
13. 45 dB
Max. limit value of
electron gain
Iris Limit
1. F3.2
2. F3.8
3. F4.5
4. F5.4
5. F6.3
6. F7.8
7. F9
8. F11
Max. limit value of iris
WDR
1. Off
2. 1
3. 2
4. 3
White
Balance
Mode
1. Auto
2. Indoor
3. Outdoor
4. One Push WB
5. ATW
6. Manual
7. Sodium Lamp
Select the color
temperature mode
1. 4000k ~ 7000k
2. 3200k
3. 5800k
4. 1700k ~ 10000k
5. 1700k ~ 10000k
6. Custom
7. 2800k
One Push
Trigger
ENTER One push trigger
Manual Red 0 ~ C ~ 128
Adjustable when the
white balance mode is
set to Manual
