51
Chapter 7 DIP Switch Setting
7.1 DIP SWITCH
7.1.1 OUTPUT Switch (Switch to different output resolutions)
To switch via the OSD/ RS-232 Command is also available based on the last
executed action
7.1.2 IR SELECT (Selected by Remote control)
When using the remote control, please make sure the settings of IR SELECT and
the Camera Select of the remote control are consistent
ID Setting
1
2
3
ID Resolution Frame Rate
0
3840 x 2160
59.94P
1 50P
2 29.97P
3 25P
4
1920 x 1080
59.94P
5 50P
6 29.97P
7 25P
8
1280 x 720
59.94P
9 50P
A 29.97P
B 25P
C
Reserved Reserved
D
E
F
To Next Page
