QUICK START
Poco Quick Start Guide
4. Create Switches (conguration menu). Assign a default intensity and color to each switch.
Example Simple Switch:
Name: Aft Hardtop
Target: LG_aft_hardtop Intensity: 50% Color: Red
You can create lighting scenes by assigning multiple light groups to more than one target.
Example Scene Switch:
Name: Night Fishing
1. Target: LG_aft_hardtop, Intensity: 20%, Color: Red
2. Target: LG_fwd_hardtop, Intensity: 20%, Color: Red
3. Target: LG_underwater Intensity: 100%, Color: Green
5. Add Switches to Layout Page:
A. Select a location screen for your switch.
B. Select the plus (+) button symbol.
C. Select desired switch from list.
Note: Visual order of switches will be arranged by the order of the switch placement on layout. Switches cannot be rearranged after
they have been added to a screen, only deleted. Go to http://lumiteclighting.com/poco-quick-start for more detailed information..
6. Check Status Indicators:
• POWER Indicator - Illuminates Green if POCO is powered on, PWR line must have supply voltage between 10-30vDC.
• CH1, CH2, CH3 or CH4 Indicator –
• Illuminates Red if power is supplied to channel from fuse/breaker panel.
• Illuminates Green if power is supplied to channel input and channel is turned on inside of POCO controller;
(PLI enabled lights may be OFF even if there is power on the wire).
• Flashes Orange if PLI data is transmitted.
• Illuminates Orange if channel is dimmed through a PWM signal.
STATUS Indicator -
• Green blinking light indicates WiFi connection status:
• 0 blinks: WiFi disabled.
• 1 blink: WiFi enabled but not connected to any peers.
• 2 blinks: WiFi is connected to one or more peers.
continued...
03
STATUS Indicator -
• Blue blinking light indicates Bluetooth connection status:
• 0 blinks: Bluetooth disabled.
• 1 blink: Bluetooth enabled but not connected to any peers.
• 2 blinks: Bluetooth is connected to one or more peers.
To Next Page
