INSTALLATION
NOTICE
POCO should be mounted in a location that is not exposed to extreme temperature conditions. This device is rated for operation at
ambient temperatures between 0 F (-18 C) and 120 F (50 C) and is sealed against water ingress per IP65 standards. To prevent standing
water, it is recommended to mount the POCO device on a vertical surface protected from continuous water exposure.
• Using the included hardware, you can surface mount the device close to a breaker panel or fuse block.
• Pre-drill mounting holes with appropriately sized bit depending on the material. Typically a #32 (.116 inch) or 3mm bit can be
used for pre-drilling for the #6 self tapping screws.
• Ensure screw holes do not interfere with anything on the opposite side of the mounting surface.
• The location must allow room for routing, the connection of all cables, visibility of LED indicators and access to depress the
reset button.
SUPPLY
Poco must be powered with a 10-30 VDC supply independently fused with a 3 Amp ATC blade fuse or equivalent (Not Provided).
ACC - Poco Accessorty Bus Blue Wire
Connect to blue accessory bus wire to multiple expansion moudles from Lumitec. Works with up to 4 Pico S8 Modules for expansion.
INPUTS
Notice: POCO is designed to switch DC voltages between 10 and 30 volts. Switching any AC line voltages or DC voltages higher than 30V is
not permitted and failure to adhere to the input voltage requirement can cause serious injury and death.
Each channel is independently powered and switched inside the POCO device allowing for many different wiring methods depending
on system requirements. Each input line must be fuse protected prior to the POCO digital switch with a 10 Amp ATC or equivalent
protection device. Input voltage must be between 10 VDC and 30 VDC. Switching of AC or high voltage lines is not permitted without
properly rated relay and integral yback diode. Contact Lumitec for further information. POCO comes with 16 inches (400 mm) 14 AWG
wire for each channel input. Use appropriately sized and sealed crimp terminals to connect with channel supply.
Mounting
Connections
Installation continued...
07
