INTEGRATED AMPLIFIER L-590AX
3
Phono amplifier
This unit is equipped with a phono amplifier that is compat-
ible with the MM/MC cartridge to achieve analog record re-
production in a high-grade level without adding a dedicated
phono amplifier.
Separate function
This unit is equipped with a separate switch to separate the
pre-amplifier and power-amplifier each other that enables the
bi-amp connection adding a power-amplifier and the coexis-
tence with an AV system.
Loopless chassis structure
This unit consists of the independent construction of a
loopless chassis to eliminate increased ground impedance
caused by chassis current.
18 mm pitch RCA terminal
Introduction of 18 mm pitch all RCA input/output terminals
allows even a high-performance line cable with large plug to
be connected.
Large type of speaker terminals
Speaker terminals (A and B systems) of inline layout (with
same characteristics for right and left), which is compatible
with Y lugs and banana plugs to enable easy connection with
extra-thick speaker cables.
Ventilation
For enhancing the heat radiation efficiency of this unit, ventila-
tion holes on the top board are wider than our conventional
models.
New standard size
This unit has been manufactured based on LUXMAN's new
standard size (440mm wide, common with a series of sepa-
rate amplifiers and a series of SACD players.
Cast-iron insulator
This unit is equipped with gradation cast-iron insulators that
cuts out unnecessary external vibration and strongly supports
the weight of this unit.
Headphone output terminal
This terminal allows you to casually enjoy sound even at mid-
night.
AC inlet
This inlet enables the connection with an external power ca-
ble.
Hairline finish for the top board
Application of surface treatments such as blasted white for
the main unit and sophisticated hairline finish for the top
board.
Needle-type meter
This unit is equipped with needle-type meters lighted with
LED, which improves the visibility in the room where the unit
will be installed.
Remote control encased in aluminum
The high-grade remote control, which is encased in alumi-
num, can control applicable CD/SACD players.

Luxman L-590AX Specifications

General

Type	Integrated Amplifier
Output Power	30W + 30W (8Ω), 60W + 60W (4Ω)
Input Impedance	47kΩ (LINE)
Frequency Response	20Hz-20kHz (+0, -0.5dB)
Signal-to-Noise Ratio	105dB (LINE)
Dimensions	440 x 193 x 463 mm
