Appendices
CABLES
Included with
AES16-XLR and
AES16-SRC
CBL-AES1604 (qty 2): 26-pin high-density male D-sub to four female
XLR’s (AES inputs), four male XLR’s (AES outputs), and two female
BNC’s (word clock I/O). Six- foot, 110-ohm shielded twisted pair cabling.
Optional cables
for AES16
Standard Model
CBL-AES1603: 26-pin high-density male D-sub to 25-pin male D-sub.
Supports either 8 channels of input or output. Compatible with Apogee
AD16 and DA16. Twelve-foot, 110-ohm shielded twisted pair cabling.
CBL-AES1605: 26-pin high-density male D-sub to 25-pin male D-sub.
Supports 4 channels of input and output. Compatible with devices with
standard Yamaha digital I/O pinout from Yamaha, Apogee, Mackie, and
others. Twelve- foot, 110-ohm shielded twisted pair cabling.
Other cables to be offered for connection to equipment from Tascam, Sony,
and Digidesign
AES16 User Manual 76
