15
USB Cradle
M3‟s USB Cradle supports charging function and USB port connection.
The following procedure describes how to connect M3‟s USB cradle:
1. Connect the battery charger to USB cradle.
2. Connect the battery charger to the power outlet.
3. Connect the USB cable of USB cradle to the USB port of a desktop PC.
4. Insert M3 into the USB cradle and carry out the synchronization with the desktop PC.
For details of the synchronization with a desktop computer, refer to the CD manual
chapter 4, How to connect to a desktop PC.
The pictures below show how to connect M3 with the USB cradle. The location of USB
input terminal can be the back, front, or side of the computer. The shape of USB input
terminal is same for both desktop PC and notebook.
[Connecting to USB cradle] [Connection between PDA and Computer‟s USB]
