Dual Stage Agitator
To remove the dual action agitator, the cup section needs to be removed to access the
7/16
th
in. hex bolt. The bolt is located inside the agitator at the bottom. A long socket
extension (at least 17 in. long) will be needed to remove it.
Note.- Agitator bolts should be replaced any time it is removed for service and torqued
to 100 +/- 5 in-lbs.
