Single Stage Agitator
Remove the single action agitator by taking the agitator cap off to access the 7/16
th
in.
hex bolt. The bolt is located inside the agitator at the bottom. A long socket extension
(at least 17 in. long) will be needed to remove it.
Note.- Agitator bolts should be replaced any time it is removed for service and torqued
to 100 +/- 5 in-lbs.
