Service Mode Tests
Knob Index / Test
number (Displayed
on SSD, 7-segment
display, if present)
(Without SSD will
be displayed in
binary format. (See
Binary Chart)
Test Name
Description of test
If tests call for numbers to be shown it will:
(Display on SSD, 7-segment display, if present)
(Without SSD will be displayed in binary format.
(See Binary Chart) Turning the cycle knob will
index to the next or prior test.
0
All LEDs on
All LEDs on the display will be blink including “88”
on the (7-segment display) SSD at a rate of 1 Hz.
1
Fault Codes
Models without 7-segment display:
Faults will be shown:
- On Start button press, blink first fault code in
binary. (See Binary Chart)
- On next Start button press, blink next fault
code.
- At end of list OR if no fault codes are present,
blink all LEDs.
- Pressing Start at the end of the fault list will
wrap back around.
- Use the fault sequence.
7-segment display models:
On Start button press, blink first fault code
Display fault code in SSD
At end of list OR if no fault codes are present,
washer will flash “- -“.
2
Personality
ID
Pressing Start will start the test.
Flash the set personality after pressing Start.
Models without SSD use binary to show
personality.
Model with SSD will display personality.
(See Personality ID Chart for the correct ID for
the model being checked).
