Service Mode Tests
Knob Index / Test
number (Displayed
on SSD, 7-segment
display, if present)
(Without SSD will
be displayed in
binary format. (See
Binary Chart)
Test Name
Description of test
If tests call for numbers to be shown it will:
(Display on SSD, 7-segment display, if present)
(Without SSD will be displayed in binary format.
(See Binary Chart) Turning the cycle knob will
index to the next or prior test.
3
UI Software
Version
(Critical)
After entering this test, press the Start button to
toggle through the software version number as
follows:
Example: v01.23
High end UI
1
st
press – “01” on 7SD
2
nd
press – “23” on 7SD
Low end UI (See Version Diagram below)
Major version (Pause LED ON)
3
rd
press – Display 2 in binary
4
th
press – Display 3 in binary
4
UI Software
Version (Non-
critical)
After entering this test, press the Start button to
toggle through the software version number as
follows:
Example: v01.23
High end UI
1
st
press – “01” on SSD
2
nd
press – “23” on SSD
Low end UI (See Version Diagram below)
Major version (Pause LED ON)
1
st
press – Display 0 in binary (all LEDs off)
2
nd
press – Display 1 in binary
Minor version (Lid Locked LED ON)
3
rd
press – Display 2 in binary
4
th
press – Display 3 in binary
