Service Mode Entry
Field Service Mode Entry
From an idle state only (all LEDs off), press and hold Start button while rotating the
cycle selection knob 180 degrees (7 clicks) and then release the Start button.
 Once service mode is entered all LEDs will be flashing.
o On 7-segment display models: (0) will be displayed for test (0).
o On models without a 7-segments display: All of the status LEDs above the
cycle knob will be lit.
 The cycle selection knob is now used to control the test selection menu.
o Rotating the knob clockwise will increment the test numbers in the display.
o Rotating the knob counter clockwise will decrement the test number in the
display.
o Models without 7-segment display: Will display test using the status lights
above the cycle knob in a binary format. (See Binary Chart).
o Turning the knob to go to a different test will terminate any current active
state.
 Once the test number is selected, pressing Start will begin the selected test.
Exit Field Service Mode
 Field service mode will time out after 30 minutes if there is no user activity.
 Models without 7-segment display: Press and hold the Start button for 3 seconds.
 Models with a 7-segment display: Press Power button.
Once the washer is in Service Mode, the following service features are available via the
cycle knob (on some models):
