Fault Codes
Fault
Code
(Hex)
Name
Description
Repair Action
1
Lock
Monitor
Lid lock didn’t occur
or lid lock signal not
seen by control due
to lack of connection.
 Check the resistance of the lid lock assembly.
 Check the harness for open wires and or
connectors from the board to the lock
assembly.
 If lock assembly and harness prove good at
the time of service, replace the lid lock
assembly.
2
Lid
Monitor
Control did not get lid
closed signal from
switch while motor
was moving. Could
mean the switch
didn’t close or control
didn’t get the signal
because of lack of
connection.
 Replace control if this fault happens
repeatedly.
3
Locked
Rotor
Monitor
For 5 straight
seconds control not
seeing signal
changes indicating
the motor is turning
while trying to spin.
Could mean the
motor isn’t rotating or
Control didn’t get the
signal because of
lack of connection
 Physically check the washer for anything
preventing motor movement.
 Check harness and harness connections from
the control to the motor.
 Verify hall sensor is connected to the main
harness. Put washer in Service Mode and run
Test 13. Spin Test. If hall sensor is bad or
disconnected, the basket will start to spin
normally and then stop spinning after
approximately 5 seconds. Ensure hall sensor
is properly connected and positioned on the
motor. If basket spins for approximately 15
seconds, the hall sensor is most likely NOT the
cause.
 TCO should reset in approximately 45 minute.
If TCO is tripped, make sure motor moves
freely and that nothing is jamming it. Replace
motor if it does not.
