mabe Kraken - Page 59

Ingeniería de Servicio
- 59 -
Service Mode Tests
Knob Index / Test
number (Displayed
on SSD, 7-segment
display, if present)
(Without SSD will
be displayed in
binary format. (See
Binary Chart)
Test Name
Description of test
If tests call for numbers to be shown it will:
(Display on SSD, 7-segment display, if present)
(Without SSD will be displayed in binary format.
(See Binary Chart) Turning the cycle knob will
index to the next or prior test.
5
XML Version
(Non-Critical)
Example: v01.23
High end UI
1
st
press – “01” on SSD
2
nd
press – “23” on SSD
Low end UI (See Version Diagram below)
Major version (Pause LED ON)
1
st
press – Display 0 in binary (all LEDs off)
2
nd
press – Display 1 in binary
Minor version (Lid Locked LED ON)
3
rd
press – Display 2 in binary
4
th
press – Display 3 in binary
NOTE: We only show the non-critical version
number because the critical XML version number
must match the application non-critical version
number for the control to boot. If you get to
service mode, then the XML critical version is
correct. If not, update software.
6
Hot Water
Valve
Pressing Start will toggle the hot water valve on
and off. Test will have a timeout for how long
valve will be on (1 minute). The valve will turn off
when the test is exited.
7
Cold Water
Valve
Pressing Start will toggle the cold water valve on
and off. Test will have a timeout for how long
valve will be on (1 minute). The valve will turn off
when the test is exited.
