Service Mode Tests
Knob Index / Test
number (Displayed
on SSD, 7-segment
display, if present)
(Without SSD will
be displayed in
binary format. (See
Binary Chart)
Test Name
Description of test
If tests call for numbers to be shown it will:
(Display on SSD, 7-segment display, if present)
(Without SSD will be displayed in binary format.
(See Binary Chart) Turning the cycle knob will
index to the next or prior test.
8
Fabric
Softener
Dispenser
Pressing Start will toggle the fabric softener valve
on and off.
Test will have a timeout for how long valve will be
on (1 minute). The valve will turn off when the
test is exited.
9
Spray Rinse
Valve Check
Pressing Start will toggle the spray rinse valve on
and off.
Test will have a timeout for how long valve will be
on (1 minute). The valve will turn off when the
test is exited.
10
Pressure
Sensor
Pressing Start will start the test.
Pressure sensor test will have a time out.
All valves will turn on.
All LEDs will blink at start of test.
Stop blinking LEDs as approximate water levels
are crossed.
The levels are:
2”
3”
4”
5”
6”
7” Water valves shut off at this level.
11
Recirculate
Pump
Pressing Start will toggle the recirculation pump
on and off.
Test will have a timeout (1 minute) for how long
recirculation pump will be on.
The recirculation pump will turn off when the test
is exited.
