SECTION 7 MAINTENANCE AND SERVICING
Form 169000 / 169040 109 Revision D
A30-D Headers (Cont’d)
CROSS SHAFT BEARING (1 PLC)
NOTE
To prevent binding and/or
excessive wear caused by sickle
pressing on guards, do not
over-
grease. If more than 6 to 8 pumps
of grease gun are required to fill
the cavity, replace the seal in the
sickle head.
AUGER SHAFT BEARING (1 PLC)
REEL SHAFT BEARING (1 PLC)
High Temperature Extreme Pressure
(EP2) Performance With 1% Max
Molybdenum Disulphide
(NLGI Grade 2) Lithium Base.
A30-D HEADER LH SIDE
SICKLE HEAD BEARING (1 PLC)
