OPERATION
3. Operate the hitch swing control lever to rotate the
mower conditioner to the right. The mower conditioner
will stop when it reaches operating position.
Figure 3.90: Mower Conditioner Rotation
4. Continue operating the hitch swing control lever to
fully raise the transport assembly and lower the mower
conditioner onto the field wheels.
5. Move transport switch to the lower position and ensure
that th e light on the remote control is illuminated.
Transport conversion is now complete and the hitch
swing circuit is active.
Figure 3.91: Transport Switch
147910 78 Revision A
