SPECIFICATIONS
Form # 169053 15 Model Year - 2010
5 SPECIFICATIONS
(continued next page)
HEADER MODEL
R80 – 13 FT R80 – 16 FT
FRAME & STRUCTURE
Width
13 ft-0 in. (3952 mm) 16 ft-3 in. (4957 mm)
Weight (estimated) 6200 lb (2818 kg) 7130 lb (3240 kg)
Carrier
Pull-Type
Lighting
Two Amber Transport and Two Red Tail-Lights
Wheels/Tires
16 in. / 10.00x16 – 4 Rib 16 in. / 14Lx16.1 8 Ply
Tread Width
143 in. (3265 mm) 150 in. (3800 mm)
Manual Storage
Plastic Case In Header RH Drive Compartment
CUTTERBAR
Qty Of Cutting Discs
8 10
Knives Per Disc
Two 18 Deg. Bevel Down Reversible (11 Deg. Optional)
Disc Speed 2530 rpm
Knife Tip Speed Range
184 mph (82.9 m/s)
Effective Cutting Width
12 ft-9.37 in. (3895 mm) 16 ft-0.87 in. (4899 mm)
Cutting Height
1 to 3 in. (25-75 mm) Without Lift Kit 1 to 3 in. (25-75 mm) Without Lift Kit
Oil Capacity (Maximum)
7 Pints (3.25 Litres) 9 Pints (4.25 litres)
Cutting Angle Range
0-8 Deg Below Horizontal
Geartrain Protection
Shearable Disc Spindles
Deflectors 2 Hourglass Converging 6 Hourglass Converging
DRIVES
Tractor PTO 1.375 in. (35 mm) Dia. 21 Spline or 1.75 in. (44 mm) Dia. 20 Spline
Connections Quick Attachment Coupling
Hydraulic Pump Step-Up Gearbox to 4.9 cu in. (80 cc) Pump
Hydraulic Motor
3.7 cu in. (60 cc) To Gearbox
Power Developed (max) 143 hp (107 kW)
Normal Operating Pressure 2000 psi (13.71 MPa)
CONDITIONER
Drive Bevel Gearbox To Belt Driven Enclosed Timing Gearbox And Driveline.
Bevel Gearbox Lub.
Capacity
0.9 Pints (0.4 Litres)
Roll Type Intermeshing Steel Bars
Main 9.17 in. (233 mm)/6.62 in. (168 mm) OD Tube
Roll Diameter
Lifting 9.21 in. (234 mm)/6.62 in. (168 mm) OD Tube
Main 118 in. (3000 mm)
Roll Length
Lifting 118 in. (3000 mm)
Main 1035 rpm
Roll Speed
Lifting 690 rpm
Swath Width 36-102 in. (915-2540 mm)
Forming Shields
Header Mounted Adjustable Baffle, Fixed Side Deflectors, and Header Mounted Adjustable Forming
Shield System.
