D8B Manual • Chapter 1 • page 18

Physical Dimensions

37.6" (955mm)

8.7"

(221mm)

27.1" (688mm)

D8B

CONSOLE

SHIPPING

WEIGHT

73 lbs.

(33.1 kg)

D8B CPU

SHIPPING

WEIGHT

50 lbs.

(22.7 kg)

19.00" (48.3cm)

CPU

17.25" (43.8cm)

5.25"

(13.3cm)

3U

20" (50.8cm)
