© 2015 MacroAir Technologies Toll Free: 866 668 3247 Fax: 909 890 2313 www.macroairfans.com 8
Rev. Date 090415
Model 550
The Model 550 has a standard airfoil to mount clearance of 3 feet [0.914 m] with the Rapid Mount
Industrial. A clearance of less than this can be achieved by using a Rigid Mount. Refer to the Fan
Clearance & Placement charts on pages 5 and 6 for allowable mounting options.
Model 780
The Model 780 has a standard airfoil to mount clearance of 3 feet - 2 inches [0.953 m] with the
Rapid Mount industrial. A clearance of less than this can be achieved by using a Rigid Mount.
Refer to the Fan Clearance & Placement charts on pages 5 and 6 for allowable mounting options.
Fan Dimensions
6.105
20'-0"
0.953
3'-2"
1.092
3'-7"
ILLUSTRATION
SHOWN WITH
STANDARD EXTENSION
0.556
1'-9.875"
20' AirVolution D
700 Series
Rapid Mount Industrial
A-01
DO NOT SCALE DRAWING
MA20XL7806
SHEET 1 OF 1
9/12/2014
7/17/2014
7/17/2014
xxxx
xxxx
xxxx
xxxx
MD
JH
EV
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:60
WEIGHT:
REV
DWG. NO.
A
SIZE
TITLE:
MacroAir
794 S Allen St. San Bernardino, CA 92408
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
MacroAir TECHNOLOGIES. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
MacroAir TECHNOLOGIES IS
PROHIBITED.
5
4
3
2
1
DIMENSIONS ARE IN FEET AND INCHES
BRACKETED DIMENSIONS ARE IN METERS
TOLERANCES:
FRACTIONAL
.010
ANGULAR: MACH
1
BEND
1
TWO PLACE DECIMAL
.01
THREE PLACE DECIMAL
.001
