MacroAir Technologies AirVolution 550 - Rapid Mount Industrial

© 2015 MacroAir Technologies Toll Free: 866 668 3247 Fax: 909 890 2313 www.macroairfans.com 11
Rev. Date 090415
Rapid Mount Industrial
Components:
A - Locking Hardware
B - Top Plate
C - Drop Length Attachment Point
WARNING: Do not disassemble the inner portion (ball) of the mount for any reason.
A
B
C
