Macrom M-OF7070 User Manual

- 24 -
General
Reference Supply Voltage ....................................................................................................... 12V(DC)
Operating Voltage Range .................................................................................................11 - 16V(DC)
Max Operating Current ................................................................................................................... 15A
Grounding System ..................................................................................... Car Battery Negative Pole
Dimensions(WXHXD) .................................................................................................246x137x172mm
Weight(main unit) ...................................................................................................................... 2.26kg
FM
Signal Noise Ratio ....................................................................................................................
≥
55dB
Residual Noise Sensitivity (S/N=30dB) ..................................................................................18dBμV
Frequency Response (±3dB) ...................................................................................... 20Hz~12.5KHz
Station Seeking Level .......................................................................................................20~28dBμV
Distortion ..................................................................................................................................
≤
1.0%
Stereo Separation (1KHz) .........................................................................................................
≥
25dB
Antenna Impedance ......................................................................................................................75
Ω
AM
Residual Noise Sensitivity (S/N=20dB) ..................................................................................30dBμV
Selectivity (±9KHz) ....................................................................................................................
≥
50dB
LCD
Screen size .................................................................................................................. 7 inches (16:9)
Display resolution .......................................................................................................... 800X480dots
Contrast ratio ................................................................................................................................ 500
DVD Player
Signal / Noise Ratio ....................................................................................................................75dB
Dynamic Range ...........................................................................................................................75dB
Output Power
Maximum Output Power ......................................................................................................... 4×40W
Load Impedance ............................................................................................................................ 4
Ω
Distortion (line out) ...................................................................................................................
≤
0.1%
Frequency Response (±3dB) ......................................................................................... 20Hz~20KHz
AUXIN
Distortio ....................................................................................................................................
≤
0.5%
Frequency Response (±3dB) ......................................................................................... 20Hz~20KHz
Audio Input Level ..................................................................................................................0.5 Vrms
Audio
Audio Output Impedance ............................................................................................................10k
Ω
Audio Output Level ..................................................................................................................2 Vrms
Video
Normal Video Input Level (CVBS) .........................................................................................1.0±0.2V
Video Input Impedance .................................................................................................................75
Ω
Video Output Impedance ..............................................................................................................75
Ω
Video Output Level .................................................................................................................1.0±0.2V
Environment
Operating Temperature ...............................................................................................-10°C ~ +60°C
Storing Temperature ...................................................................................................-20°C ~ +70°C
Operating Humidity ........................................................................................................ 45%~80%RH
Storing Humidity ............................................................................................................ 30%~90%RH
Notice:
When the unit is operated to extremes, such as with maximum power output for a long time,
or the temperature is over 70°C, it will enter heat protection mode, the volume will be reduced
automatically. This is normal.
