Front Panel
Product overview
Notice:
The graphic in this manual is for reference only, and may be different from the actual unit.
1
2
4
5
7
12131415
1. Microphone: Internal microphone for Bluetooth calls.
2. [MENU] button
Press to switch between the available audio/video sources applied to the unit.
3. [RADIO] Button
Press to enter the radio Mode. Press to switch radio band (FM/AM).
4. [Navigation ] button
Press to switch to navigation mode.
5. Press the DISC to access the disc mode.
6. [ VOL/
/ ] Knob
Press to turn the unit ON. Press and hold to turn the unit OFF.
Rotate to adjust the volume. Press momentarily to activate the MUTE function. Press again to
resume normal listening.
7. [ TUNE / SEL/
] knob:
Rotate to select next/previous track or preset station.
Play/pause(press). Enter EQ setting(long press).
8. [BT] Button: Enter the Bluetooth Mode.
9. [ ] Button: to adjust the screen brightness turn the volume knob after pressing the button
of brightness. Long press to dim the screen.
10. A/V Input. Accepts a 3.5mm jack through which signals from various audio/video devices can
be applied to the unit.
11. SD/SDHC card slot: Insert an SD card for playback of music/video/picture files.
12. Reset Button
Press to reset system settings to factory default (except password and parental lock settings).
13. Map Slot: The SD card is used for the Navigation Map only, not for music or other files.
14. Disc slot
15. [ ] Button: Press to eject a disc.
DISC
BT
RADIO
3
6
8
9
10
11
