Macrom M-OF7070 User Manual

- 26 -
Wire Connections
Red
White
Red
White
Brown
Yellow
FRONT R
FRONT L
REAR R
REAR L
SUB OUT
VIDEO OUT
GPS
Antenna
AV-IN (video)
Yellow
Audio L
White
Audio R
Red
Fuse 15A
Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Front right / Gray
Front right (-) / Gray with black stripe
Front left (+) / White
Front left (-) / White with black stripe
ACC+ / Red
Rear left (+) / Green
Ground / Black
Battery 12V(+) / Yellow
Rear left (-) / Green with black stripe
Function
Connector A Connector B
PIN NO.
WHITE
RED
ISO Connector
to Car USB
USB
to Radio Antenna
Car Connector
BRAKE
REVERSE
AMP_CONT
Yellow
CAMERA
CAM_POWER
GND
A
B
ILLUMI
CTL ACC
KEY ACC
CAN-High
CAN-Low
Illumination / Pink
