Magellan Meridian Series User Manual

36 Magellan Meridian GPS Receiver
Reference
From the
Position
Screen
MENU
Highlight
Customize
Use arrows to
highlight the title
for the data field to
be changed
Use arrows to
select new
data type
ENTER ENTER
ENTER
GPS Status Messages — Messages indicating the status of the GPS receiver
section of the Meridian are displayed on the Position screen.
Message Description
Searching - 1st sat Searching for 1st satellite.
Searching - 2nd sat 1st satellite found; searching for 2nd satellite
Searching - 3rd sat Two satellites are being tracked and searching
for a third.
Searching - 4th sat Three satellites are being tracked and
searching for the fourth.
Collecting Data All satellites needed for position fix are being
tracked and position is being computed.
Averaging Meridian is computing fixes; speed is near 0.0
so position is being averaged.
EPE xxft Estimated Position Error in feet. Meridian is
computing fixes while moving.
DGPS Computed fixes are being differentially
corrected.
Since the Meridian is a 12-channel receiver, once the first satellite is
found, finding the remaining satellites and computing a fix may take
only a few seconds.
Selecting Coordinate System, Map Datum and Elevation Mode —
Allows you to change the coordinate system, map datum and elevation
mode for the primary and secondary Position Screens. These functions
perform identically to the same functions described in the Setup section
of this manual. Simply described, you press [MENU] from either
Position screen, select the option, press [ENTER] and follow the
prompts.

Magellan Meridian Series Specifications

General

Display Type	LCD
Screen Size	2.2 inches
Waypoints	500
Routes	20
Track Log	2000 points
Battery Type	2 AA batteries
Type	Handheld GPS
Brand	Magellan
Series	Meridian
Channels	12
Memory	8 MB
Waterproof	Yes (IPX7)
