MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00 Pag. 9
2.6. TECHNICAL DATA
2.7 NOISE EMISSIONS
Noise emission according to correct working of machine and balancing and grinding of tools, is variable and
depends on working material, drill diameter and depth drill. The operator permanence expected time is
variable during 8 hours a day. Some other factors may determinate the exposure level; the surroundings and
other noise sources, and other close machines.
We suggest to inform the operators about risks caused by a prolonged exposure to noise, providing them with
suitable individual protection devices.
The acoustic pressure level, collected in the operator place through class 1 integrative noise meter, is 76.1 dB
(A).
This measure was done according to ISO3745 rules with usual working values of speed and air pressure,
drilling a shaving wood PVC covered panel.
The measure was executed at 1.5 m from ground, in front of the machine, in the operator position.
Moreover the following reference measures were collected with the same procedure:
Acoustic pressure level in Atm. dB(A): 78.3
Acoustic pressure power dB(A): 93.3
NUMBER OF SPINDLES
23
INTERAXIS BETWEEN SPINDLES
32 mm
INTERAXIS BETWEEN FIRST AND LAST SPINDLE
704 mm
MAX. BORING DEPTH
65 mm
MAX. DIMENSIONS OF THE WORKING PIECE
960 x 3000 mm
HEIGHT OF THE WORKING TABLE
867 mm
NUMBER OF CLAMPS
2
NUMBER OF MOTORS
1
MOTOR POWER
2 (1,5) HP( KW )
MOTOR R.P.M.
2800 RPM
NET WEIGHT
265 Kg
1285 mm 872 mm
1300 mm
