MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00 Pag. 11
3. HANDLING AND TRANSPORT
The machine is packed in a wooden box. It is possible to move it by means of forklift or transpallet.
Weight data are written in the chapter TECHNICAL DATA, lifting points and the position of the center of
mass are shown below.
machine in the box
CENTER OF MASS
MACHINE IN THE BOX
BE EXTREMELY CAREFUL IN LIFTING, MOVING, TRANSPORTING THE MACHINE
THE DEVICES USED TO LIFT-MOVE-TRANSPORT THE MACHINE MUST BE CAPABLE TO
DO THE DUTY WITH NO RISK FOR PERSONS AND THINGS
NO ONE MUST STAY INSIDE A RANGE OF 5 METERS AT LEAST AROUND THE MACHINE
DURING LIFTING AND TRANSPORT OPERATIONS
DAMAGE TO THE MACHINE CAUSED DURING TRANSPORT AND HANDLING ARE NOT
COVERED BY WARRANTY.
REPAIRS / REPLACEMENTS OF DAMAGED PARTS ARE CHARGED TO THE CUSTOMER.
CENTER OF MASS OF THE MACHINE
DPI - WEAR
PROTECTIVE
CLOTHES
DPI - WEAR
PROTECTIVE SHOES
DPI - WEAR
PROTECTIVE
GLOVES
GX = 600 mm
GY = 410 mm
GZ = 710 mm
GX = 515 mm
GY = 615 mm
GZ = 715 mm
To Next Page
