MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00 Pag. 41
FRAME UNIT
POS. CODE PART NAME
Q. TY
1 00000005 GROWER WASHER Ø8 UNI-1751 3
2 00000009 GROWER WASHER Ø12 UNI-1751 1
3 00000151 NUT M10 10
4 00001189 GLAND PG 13,5 2
5 00001198 GLAND M20×1,5 2
6 00001341 ELECTRICAL TERMINAL BOTECO R537126M20.P01 1
7 00005082 FUSIBLE 10X38 0,5A 2
8 00005083 FUSIBLE 10X38 1,0A 1
9 00005086 TAP PG13,5 2
10 00005320 LAMP HOLDER SCHNEIDER XB7-EV67P 1
11 00005330 EMERGENCY BUTTON SCHNEIDER EB7ES542P 1
12 00005340 FUSE WIMEX PS 10-1-S 32A 10X38 1
13 00005341 FUSE WIMEX PS 10-2-S 32A 10X38 1
14 00005353 POSITION SWITCH EATON PKZM0-63 1
15 00005360 COUNTER EATON DIL EM-10 XTMC9A10 1
