Pag. 42 MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00
FRAME UNIT
POS. CODE PART NAME
Q. TY
16 00005370 MAIN SWITCH GIOVENZANA SQ0321003B 1
17 00005380 LIGHT BULB 30V 3W 1
18 00005390 ELECTRIC TRASFORMER NOR-SE VA15 TA-980015 1
19 00015220 PNEUMATIC PEDAL 228.52.10.2/1 + T010818 + SEP18 1
20 00015221 PRESSURE SWICHT 1/8 COD.PMN10A 1
21 00015229 FLUX REGULATOR 6.01.18NE + N°2 T150818 PNMX 1
22 00015805 FLUX REGULATOR 290818 1
23 00015825 REDUCER FILTER + MANOMETER + FITTINGS 1
24 00015900 FITTING PNMX 10318 1
25 00018290 SCREW VTCEI M4x12 2
26 00018325 SCREWTCEI M6X16 UNI-5931 2
27 00018474 SCREW TSPEI M4x10 UNI-5933 4
28 00018499 NUT M4 UNI-5588 6S 2
29 00018500 NUT M6 UNI-5588 6S 2
30 00018501 NUT M8 UNI-5588 6S 3
31 00018503 NUT M10 UNI-5588 6S 1
32 00018507 NUT M12 UNI-5588 6S 1
33 00018522 WASHER Ø10 UNI-6592 2
34 00018620 SCREW VTBEI M4 x 8 ISO 7380 6
35 00018627 SCREW TBCEI M10X16 ISO-7380 1
36 00018804 SCREW VTE M10x20 10
37 26054900 PNEUMATIC KIT 1
38 26054901 SELECTOR UNIT + FLOW REGULATOR 1
39 36003014 LABEL LOGO MAGGI 1
40 36003016 LABEL MAGGI 1
41 36028002 FRONT PLATE 1
42 36028004 CONTROL PANEL 1
43 36028005 TANK 1
44 36030001 SUPPORT 3
45 36030002 SUPPORT 1
46 36030005 ADJUSTABLE SUPPORT 1
47 36054016 LABEL GENERAL WARNING 1
48 36054033 ELECTRIC BOX 1
49 36055001 RH SIDE PLATE 1
50 36055002 LH SIDE PLATE 1
51 40000030 ETICHETTA 3M 68x46 3690-906 1
52 40000035 TARGA ACIMALL 1
53 40001011 TARGA TERRA 1
54 40001016 TARGA NORMATIVE RUSSIA EAC FONDO BIANCO 1
55 45400082 TARGA VOLTAGGIO 400 V 2
