Pag. 40 MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00
13. SPARE PARTS
POS. CODE PART NAME Q.TY
1 26003302 LH SQUARE UNIT 1
2 26003303 RH SQUARE UNIT 1
3 26028001 FRAME UNIT 1
4 26028101 TABLE UNIT 1
5 26028201 RACK UNIT 1
6 26028501 CLAMPING UNIT 1
7 26028812 EXTENSION FEENCE UNIT 1
8 26054602 BACK STOP UNIT 1
9 26054700 SPINDLE HEAD SUPPORT UNIT 23 1
10 26271400 HEAD UNIT 1
