Maggi BORING SYSTEM 23 - Page 57

Pag. 48 MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00
RACK UNIT
POS. CODE PART NAME
Q. TY
1 00000147 NUT M12 UNI-7473 2
2 00000150 NUT M10 UNI-7473 1
3 00003460 BEARING INA AXK1024 2
4 00003461 RING INA AS 1024 4
5 00003905 SNAP LEVER ART.562-104 M 12 1
6 00003920 SNAP LEVER 563-43 M6 L20 1
7 00003969 GAMM 3 LOBE 6389030 VTB/30 M8 1
8 00015400 OVERTURNING 1
9 00018295 SCREW STEI M4 x 8 UNI-5923 2
10 00018307 SCREW TCEI M8X16 UNI-5931 2
11 00018402 SCREW VTE M10x25 1
12 00018404 SCREW TE M8x35 UNI-5739 1
13 00018473 SCREW VTE M6x16 4
14 00018501 NUT M8 UNI-5588 6S 1
15 00018520 WASHER Ø6 UNI-6592 5
16 00018522 WASHER Ø10 UNI-6592 1
17 00018523 WASHER Ø13 UNI-6592 2
18 00018524 WASHER Ø17 UNI-6592 2
19 00018534 WASHER Ø12x36 UNI3351 1
20 00018590 WASHER M20 UNI 6592 1
21 00018755 SCREW VTCEI M16x80 UNI 5931 2
22 36003204 INNER TIE ROD 1
23 36028202 RACKS 23 1
24 36011203 SUPPORT 1
25 36050206 OVERTURNING CYLINDER CATCH 1
26 36054203 INNER TIE ROD 1
27 36054204 LOCKING BUSH 1
28 36054206 FENCE STOP 1
29 36054207 RUBBER FENCE 1
30 36054209 SPACER 1
31 36057205 GRADUADED FENCE 1
