Pag. 50 MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00
SPINDLE HEAD SUPPORT UNIT
POS. CODE PART NAME
Q. TY
1 00000168 SELF LOCKING M17x1 1
2 00000180 NUTM10 UNI-5589 6S 1
3 00000236 PARALLEL KEY 4x4x8 UNI 6604 A 1
4 00003455 BEARING INA AXK1730 2
5 00003456 RING INA AS 1730 4
6 00003934 HANDLE BOTECO 522-104 M10 1
7 00003942 HANDLE BOTECO 216-80 1
8 00003960 COUNTER 1
9 00004116 SCREW GN 913-3 M4-6-KU 1
10 00004250 CYLINDRICAL PIN Ø6x40 1
11 00004308 ELASTIC PIN Ø5 x 25 1
12 00004326 LESS LOBRE De32 1
13 00004380 ELASTIC PIN Ø4x26 UNI-6873 1
14 00005047 BEARING PAP 4020P10 8
15 00015415 FEED CYLINDER 1
16 00018337 SCREW TCEI M10X100 UNI-5931 1
17 00018403 SCREW TE M12X35 UNI-5739 4
18 00018430 SCREW TBCEI M 6X12 ISO-7380 2
19 00018520 WASHER Ø6 UNI-6592 2
20 00018523 WASHER Ø13 UNI-6592 4
21 00018524 WASHER Ø17 UNI-6592 1
22 00018760 SCREW TCEI M16x30 UNI5931 2
23 00040512 SCREW TCEI M5X20 UNI-5931 1
24 36000048 VERTICAL SLIDING FENCE 2
25 36000050 LIFTING SCREW 1
26 36000053 RUBBER STRIKER 1
27 36000111 CYLINDER SHANK EXTENSION 1
28 36000163 OVERTURNED STRIKER 1
29 36000164 INTERNAL OVERTURNED STRIKER 1
30 36002009 HEAD SUPPORT 1
31 36050401 LIFTING SCREW CROSSPIECE 1
32 36054018 LABEL WARNING 2
33 36054019 LABEL WARNING 1
34 36054046 SPIRAL 1
35 36054402 HEAD HOLDER PLATE 1
36 36057403 SPIRAL LABEL 1
37 36090401 SPIRAL SUPPORT 1
38 36090405 SPIRAL HOLDER 1
39 36090406 WASHER 1
40 36091402 LENS HOLDER Ø32 1
41 36091403 PROTECTION 1
42 36250407 HORIZONTAL SLIDING FENCE 2
43 36251403 WASHER 1
44 41600004 SINTERED BUSHING 1
