Maggi BORING SYSTEM 23 - Page 61

Pag. 52 MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00
HEAD UNIT
POS. CODE PART NAME
Q. TY
1 00000037 WASHER PS Ø12X18X1 22
2 00000041 WASHER SCHNORR Ø6 4
3 00000042 WASHER SCHNOR Ø8 4
4 00000211 PARALLEL KEY 4x4x12 UNI-6604 A 23
5 00000220 PARALLEL KEY 5X5X18 1
6 00000250 PARALLEL KEY 4x4x18 1
7 00003305 SEEGER E12 23
8 00003337 SEEGER I 28 46
9 00003424 BEARING 6001 2RS 46
10 00003703 GREASING NIPPLE M6 x 1 1
11 00005097 GASKET Øi 20 Øe 25,5 23
12 00018302 SCREW TCEI M6X10 UNI-5931 11
13 00018338 SCREW TCEI M6X85 UNI-5931 4
14 00018500 NUT M6 UNI-5588 6S 2
15 00018520 WASHER Ø6 UNI-6592 3
16 00018655 SCREW TCEI M8x75 UNI-5931 4
17 00100614 SCREW STEI M6X20 UNI-5923 2
18 26251701 ENGINE M802T 230-400-50 2HP 1
19 36000061 BUSHES FOR QUICK CHANGE DRILL 5
20 36000062 GEAR Z21 23
21 36000063 BEARING SPACER 23
22 36000095 LABEL 23 HEAD 1
23 36001059 DRIVING SPINDLE 1
24 36001060 DRIVEN SPINDLE 22
25 36051712 ENGINE JOINT 1
26 36052702 HEAD 1
27 36052703 HEAD COVER 1
28 36054020 ROTATION LABEL 1
29 36250703 ENGINE PLATE 1
30 36367710 GREASING LABEL 1
31 45400082 LABEL VOLTAGE 1
