Maggi BORING SYSTEM 23 - Page 63

Pag. 54 MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00
BACK STOP UNIT
POS. CODE PART NAME
Q. TY
1 00003305 SEEGER E12 4
2 00003424 BEARING 6001 2RS 4
3 00003520 RING OR 2031 2
4 00004044 SNAP LEVER M6 x 30 2
5 00005102 SCREW TC Ø2,9 x 6,5 ISO7049 4
6 00018307 SCREW TCEI M8X16 UNI-5931 2
7 00018308 SCREW TCEI M8X30 UNI-5931 4
8 00018350 SCREW TCEI M8x10 UNI 5933 2
9 00018431 SCREW TBCEI M6X20 ISO-7380 4
10 00018521 WASHER Ø8 UNI-6592 8
11 00018526 WASHER Ø6x18 UNI3351 2
12 00018552 NYLON PLUG 4
13 00150800 SCREW STEI M 8x8 ISO-4026 3
14 36050607 BACK REINFORCED 1
15 36050608 CAM 4
16 36050609 FIXED DRILL SLEEVE 2
17 36050610 FIXED DRILL PIN 2
18 36050801 DOWEL 8
19 36204812 REFERENCE DOWEL 1
20 36800228 DOWEL M6 2
21 46050602 BACK STOP HOLDER 2
22 46050603 BACK STOP PROFILE 23 1
23 46050613 RH BACK STOP MILLIMETRED RULE 1
24 46050614 LH BACK STOP MILLIMETRED RULE 1
