CLAMPING UNIT
POS. CODE PART NAME
Q. TY
1 00000051 WASHER Ø10 6
2 00000151 NUT M10 6
3 00001102 FITTING PNMX T050800 1
4 00001110 FITTING PNMX T040800 2
5 00001120 GASKET PNMX R/1502/50/7 RS/Z850 2
6 00001121 RING OR PNMX COD R-1502.50.5 OR2187 2
7 00001128 SPIRAL RILSAN11 8x6 NERA 2
8 00001250 FITTINGPNMX T060814 2
9 00001999 METALLIC BRAKET D.10 (GMP 10) 3
10 00003120 KNOB ART.119-32 M5X25 2
11 00004022 SNAP LEVERA583065 M8x20 2
12 00005103 SCREW Ø 3.9x9.5 6955 2
13 00018431 SCREW TBCEI M6X20 ISO-7380 2
14 00018439 SCREW TSPEI M4x8 UNI-5933 2
15 00018500 NUT M6 UNI-5588 6S 6
16 00018512 NUTM14 UNI-5589 6S 2
17 00018520 WASHER Ø6 UNI-6592 8
18 00018602 SCREW TBCEI M10X30 ISO-7380 6
19 00018706 SCREW TSPEI M6x60 UNI-5933 4
20 00120404 SCREW STEI M4X4 UNI-5923 2
21 36056501 CLAMP SHOULDER 2
22 36052502 SPACER BLOCK 2
23 36028502 CROSSPIECE 2
24 49900051 WASHER 2
25 49900095 NYLON BUFFER 2
26 49901088 SLIDING HEAD 2
27 49901089 HEAD PIPE 2
28 49970042 PISTON CYLINDER COVER 2
29 49970047 WEDGE PISTON 2
30 49970048 THREADED CYLINDER 2
31 49970053 SPRING TO PISTON 2
32 49970146 SPRING 2
33 49971051 BOTTON HEAD 2
34 49972040 PISTON CYLINDER 2
35 49972045 LOCKNUT 2
36 49972052 CLAMP PISTON 2
