Maggi BORING SYSTEM 23 - Page 67

Pag. 58 MAGGI TECHNOLOGY - BORING SYSTEM 23 - REV00
EXTENSION FENCE
POS. CODE PART NAME Q. TY
1 00000150 SELF-BLOCKING NUT M10 UNI-7473 4
2 00003921 SNAP LEVER KRB 6356020 M8 2
3 00004020 SNAP LEVER ART 523-65 M8x40 4
4 00004214 CILYNDRICAL PIN Ø8x20 CEM. 8
5 00005102 SVREW Ø2,9 x 6,5 ISO7049 8
6 00018521 WASHER Ø8 UNI-6592 6
7 00018522 WASHER Ø10 UNI-6592 4
8 00150808 SCREW STEI M 8 x 20 UNI 5923 8
9 36000079 THREADED PIN 2
10 36001078 ALIGNMENT PIN 4
11 36001176 EXTENSION FENCE 1,5 2
12 36003078 ALIGNMENT PIN 2
13 36050801 DOWEL 8
14 36050802 SUPPORT 4
15 36054805 MILLIMETRIC LINE 0-1500 RIGHT 1
16 36054806 MILLIMETRIC LINE 0-1500 LEFT 1
17 36054807 MILLIMETRIC LINE 70-1500 LEFT 1
18 36054808 MILLIMETRIC LINE 70-1500 RIGHT 1
19 36251802 BACK STOP GF 4
