Magnetek Flex Pro - Status Lights Indicators and Warnings

Flex Pro Transmitter Instruction Manual
April 2019
Page 22 of 25
5.3 Status Lights Indicators and Warnings
Type Display Type Indication
1
Slow green flash
(Normal operation)
Transmitter on and in standby.
2 Flashing orange
Button has been pressed and the
unit is transmitting. The speed at
which the orange LED blinks is
directly related to how far down
the button is pressed.
3
1 red flash followed by a
2-second pause
Voltage goes below 1.9V during
operation – change batteries
immediately.
4
2 red flashes followed by a
2-second pause
A push button is active while
turning on the transmitter. The
button that is active will be
designated by the (25, 50, 75,
100) LEDs. See Section 5.4 Push
Button Error Table on page 23.
5
3 red flashes followed by a
2-second pause
I-CHIP error.
6
4 red flashes followed by a
2-second pause
Transmitting error, system cannot
lock on to the designated channel.
7 Solid green for up to 2 seconds
Transmitter power on with no
faults detected (prior to initiating
the START function).
8 Solid red
Stop command initiated with
receiver E-Stop deactivated.
9 Solid red
Voltage goes below 1.9V at initial
power-on – transmitter power
shuts off.
