mWing
Design and function
4 Design and function
4.1 Design
Mag010002
1
3
5
4
6
2
2
1
Fig. 3: Setup, here showing mWing
1 Room for access-control device provided by the customer, e.g. card reader
2 Space for GED (passage direction display)
3 Swing door e.g. glass wing
4 Inlay
5 Control unit MGCplus
6 Cover for control unit and drive blocking element
