Installation and assembly
7.4 Setting up foundation and placing empty conduits
7.4.1 Requirements foundation
The foundation must meet the following requirements:
› Have sufficient load-carrying capacity
› Concrete C20/25 or corresponding industrial floor
› Attachment must be able to grip securely
› Foundation cross section according to foundation and empty conduit plan
› Non-slip surface
› Horizontal and level.
ä Foundation and empty conduit plan: Page 37, Fig. 11.
For outdoor assembly, the foundation must meet the following additional re-
quirements:
› Concrete C35/45 XD 3 XF2
› Foundation depth: at least 800 mm, frost-proof. Adapt foundation depth to
the local conditions.
› Reinforcement mesh according to reinforcement plan
ä Reinforcement plan: Page 38, Fig. 12.
7.4.2 Requirements empty conduits
Observe the following points for the empty conduits:
› Place empty conduits according to the foundation plan.
› Conduits have to be planned to a sufficient length.
› Plan empty conduits required for access-control devices and other peripher-
al devices. The cabling for this is the responsibility of the customer.
IMPORTANT!
To ensure trouble-free operation, separate empty conduits must
be installed for all mains cables and control lines.
