Unpacking, scope of delivery and identification
6.3 Identification
6.3.1 Type plate
The type plate is located under the cover to the right of the drive unit. The
C-module has the type plate on the master side.
Ser.-Nr.
Made in Germany
MAGNETIC
AUTOCONTROL GmbH
D-79650 Schopfheim
6
7
10
11 12
4
8
9
Fig. 10: Type plate
1 Product name
2 Serial number
3 Power supply
4 Frequency
5 Current consumption
6 Not used
7 IP rating
8 Duty cycle for operating mode S1 "Continuous operation"
9 Ambient temperature range
10 Date of manufacture, version, printing date of the type plate
11 Barcode of the product name
12 Bar code for serial number
