24
REPLACEMENT PARTS
C
aution: Field replacement of one of the following parts requires a user calibration of the repaired unit:
items 1, 16, 22, 23, 25.
1X
74
2 3 8 9 105 6
Digit in partn°:
Partn°:
Serial n°:
X = if there are any deviations from a standard partn°
See nameplate, always provide complete partn° and
serial n° when ordering spares.
(1) Electronic module
Digit 8 Digit 9 Replacement part
H, S
1, 2, 3 Z31-2844-001
8 Z31-2844-002
F
1, 2, 3 Z31-2845-001
8 Z31-2845-002
(15) LVDT cover
Digit 9 Digit 10 Replacement part
1, 2, 3
1, 2, 5, 6, A, B, E, F, J, K 089-7837-001
3, 4, 7, 8, C, D, G, H, L, M 089-7837-002 (*)
8
all 089-7837-003 (*)
(17) Enclosing tube
Digit 9 Digit 6 Digit 10 Replacement part
1, 2, 3
3, 4, 5, A, C, D, E, F, K, L
all except E, F, G, H 032-6401-007
E, F, G, H 032-6401-010
G, H, M, N all 032-6401-010
8
all all 032-6401-014
Replacement part
(9) LVDT cover "O"-ring 012-2222-123
(18) Enclosing tube gasket 012-1204-001
(24) Cotter pin (ordering qty: 2) 010-5203-001
(3) Remote PC board
Digit 9 Replacement part
1, 2, 3 not applicable
8 030-3609-001
Housing assembly
Digit 8 Replacement part
H, S
Z39-4101-H
nn
(*)
F
Z39-4101-F
nn
(*)
(11) Housing cover
Digit 10 Replacement part
1, 2 036-4413-001
3, 4, 7, 8, C, D, L, M
036-4413-002
5, 6, A, B, J, K 036-4413-005
E, F 036-4410-003
G, H 036-4413-012
(16) LVDT assembly kit
Digit 9 Replacement part
1 089-7827-007
2
089-7827-008
3 089-7827-009
8 089-7827-010 (*)
(12) Housing cover (13) Housing cover (14) Housing cover
Digit 10
Replacement part Replacement part Replacement part
1, 2, 5, 6, A, B, E, F, J, K
004-9225-002 004-9225-002 004-9225-002
3, 4, 7, 8, C, D, G, H, L, M
004-9225-003 004-9225-003 004-9225-003
(7) "O"-ring
Digit 9 Replacement part
1, 2, 3 not applicable
8
012-2201-237
(8) "O"-ring
Digit 9 Replacement part
1, 2, 3 not applicable
8
012-2201-237
(19) Temperature extension gasket
Digit 4 Replacement part
J, K, L not applicable
all except J, K, L
012-1204-001
(4) Remote PC board
Digit 9 Replacement part
1, 2, 3 not applicable
8 030-3609-001
Housing "O"-ring kit
(contains items 5, 6, 9 & 10)
Replacement part
089-6562-002
(2) Wiring PC board
Digit 8 Digit 10 Replacement part
H, S all Z30-9151-001
F
1, 2, 3, 4, E, F, G, H Z30-9151-003
5, 6, 7, 8, A, B, C,
D, J, K, L, M
Z30-9151-004
Consult factory to obtain the correct replacement part numbers for items not listed in the tables below.
(*) includes "O"-ring (item 9)
(*) includes core (item 21)
(*)
nn
= digit 9 + digit 10 of model number
