TRANSMITTER SPECIFICATIONS
FUNCTIONAL/PHYSICAL
➀
Not applicable for FOUNDATION Fieldbus™ units.
➁
With aluminium housing only. Does not apply to models with stainless steel housing.
Description Specification
Power (at terminals) Weatherproof / Intrinsically Safe: 11 to 28,4 V DC (ATEX/IEC) - 28,6 V DC (FM)
ATEX/IEC flameproof enclosure 11 to 36 V DC (ATEX/IEC-FM)
FOUNDATION Fieldbus™ (FISCO Intrinsically Safe): 9 to 17,5 V DC
FOUNDATION Fieldbus™ (Explosion proof): 9 to 32 V DC
Signal Output 4-20 mA with HART
®
, 3,8 mA to 20,5 mA useable (meets NAMUR NE 43),
FOUNDATION Fieldbus™ H1 (ITK Ver. 5)
Span from 356 mm up to 3048 mm (14" up to 120") - others at request
Resolution Analog: 0,01 mA
Display: 0,1 cm (inch)
Loop Resistance 620 Ω @ 20,5 mA - 24 V DC
Damping Adjustable 0-45 s
Diagnostic Alarm Adjustable 3,6 mA, 22 mA, HOLD
User Interface HART
®
communicator, AMS
®
or PACTware
®
, FOUNDATION Fieldbus™
and 3-button keypad
Display 2-line x 8-character LCD
Menu Language English/Spanish/French/German (FOUNDATION Fieldbus™: English)
Housing Material IP 66/Aluminium A356T6 (< 0.20 % copper) or stainless steel
Approvals ATEX/IEC II 1 G Ex ia IIC T4, intrinsically safe
ATEX/IEC II 1 G Ex ia IIC T4, FISCO – intrinsically safe
ATEX/IEC II 1 / 2 G Ex d IIC T6, flameproof enclosure
FM, Intrinsically Safe (FISCO) and explosion proof
FOUNDATION Fieldbus™ units are FISCO (intrinsically safe) and ATEX/IEC – FM/CSA
explosion proof approved
LRS – Lloyds Register of Shipping (marine applications)
ROSTECH/FSTS – Russian Authorisation Standards
SIL
➀
(Safety Integrity Level)
Functional safety to SIL 2 as 1oo1 in accordance to 61508 – SFF of 90,6 %
Certified for use in SIL 3 loops.
Electrical Data Ui = 28,4 V, li = 94 mA, Pi = 0,67 W - ATEX/IEC
Ui = 28,6 V, li = 140 mA, Pi = 1 W - FM
Ui = 17,5 V, li = 380 mA, Pi = 5,32 W (FOUNDATION Fieldbus)
Equivalent Data Ci = 2,2 nF, Li = 3 µH - ATEX/IEC
Ci = 5,5 nF, Li = 9 µH - FM
Ci = 0,71 nF, Li = 3 µH (FOUNDATION Fieldbus™)
Shock/Vibration Class
➁
ANSI/ISA-S71.03 SA1 (Shock), ANSI/ISA-S71.03 VC2 (Vibration)
Net and Gross Weight Cast aluminium 3 kg (7 lbs) – transmitter head / electronics only
Stainless steel 8 kg (17 lbs) – transmitter head / electronics only
Overall Dimensions H 306 mm (12.05") x W 112 mm (4.41") x D 192 mm (7.56")
FOUNDATION
Fieldbus™ specifica-
tions
ITK Version 5.0
H1 Device Class Link Master (LAS) – selectable ON/OFF
H1 Profile Class 31PS, 32L
Function Blocks 1 x AI and 1 x PID, 1 x RB, 1 x TB
Quiescent current draw 17 mA
Execution time AI: 15 ms, PID: 40 ms
CFF files Downloads available from Host system supplier or www.fieldbus.org
