TRANSMITTER SPECIFICATIONS
MECHANICAL SPECIFICATIONS
PERFORMANCE
Description Specification
Cage materials carbon steel or 316/316L (1.4401/1.4404) (other materials at request)
Wetted parts Spring Inconel
®
(other materials at request)
Displacer 316/316L (1.4401/1.4404) or 316 (1.4401)
Process Connection Threaded: 1 1/2" NPT-F or 2" NPT-F or 1 1/2" Socket Weld or 2" Socket Weld
Flanged: Various ANSI or EN/DIN flanges
Displacer lengths From 356 mm (14") up to 3048 mm (120") - other lengths at request
Description Specification
Linearity Level ± 0,50 % of full span
Interface/Density ± 0,70 % of full span
Repeatability Level ± 0,05 % of full span
Interface/Density ± 0,10 % of full span
Hysteresis ± 0,05 % of full span
Response time < 1 second
Warm-up Time < 5 seconds
Ambient Temp. -40 °C to +80 °C (-40 °F to +175 °F) – electronics temperature range
-20 °C to +70 °C (-5 °F to +160 °F) – LCD temperature range
-40 °C to +70 °C (-40 °F to +160 °F) – for Ex ia and Ex d units
Storage temperature -40 °C to +85 °C (-40 °F to +185 °F)
Ambient Temp. Effect Max zero shift is 0,03 % / °C (0,017 % / °F)
Process Temp. Max +425 °C (+800 °F) for steam / + 450 °C (+850 °F) for non steam
Min -30 °C (-20 °F) for carbon steel models / -196 °C (-320 °F) for stainless steel models
Max Process Pressure 355 bar @ +40 °C (5150 psi @ +100 °F)
Density Range from 0,23 kg/dm
3
up to 2,20 kg/dm
3
Humidity 0-99 %, non-condensing
Electromagnetic compatibility Meets CE requirements (EN 61326: 1997 + A1 + A2)
Surge Protection Meets CE EN 61326 (1000V)
