MODEL IDENTIFICATION
30
A complete measuring system consists of:
1. One order code for a complete E3 Modulevel
®
transmitter.
2
. Options:
- Adjustable displacer hanger for top mounted units, cable length 2,5 m (8'). Order code 032-3110-004 – required
w
hen distance between the top of the displacer and the flange face is > dimension A (see section Dimensions) +
60 mm (2.36").
- Free of charge: E3 Modulevel DTM (PACTware™) can be downloaded from www.magnetrol.com.
- Connecting cable used with remote mount electronics (6-wire cable/shielded, not suitable for ATEX/IEC flameproof
enclosure). Consult factory for connecting cable suitable for ATEX/IEC flameproof enclosure.
1
7
2 2
3
3 7
complete order code for connecting cable
001- 023From 1 m (3,28 ft) min. to 23 m (75,46 ft) max.
Specify in increments of 1 m (3,28 ft)
