DIMENSIONS in mm (inches)
Dimension A for all models
Cage rating SG range 4 th digit 9 th digit Dimension A
150 / 300 / 600 lbs
PN 16 .. PN 100
0.23 - 0.54 J/A/M/D
1
/2/3
236 (9.29)
0.55 - 1.09 K/B/N/E 186 (7.32)
1
.10 - 2.20
L
/C/P/F
1
86 (7.32)
900 / 1500 lbs
PN 160 / PN 250
0.55 - 1.09 K/B/N/E 1/2/3
245 (9.65)
2500 lbs
PN 320
3
20 (12.60)
150 / 300 / 600 lbs
PN 16 .. PN 100
0
.55 - 1.09
N
/E
8
236 (9.29)
900 / 1500 lbs
PN 160 / PN 250
2
45 (9.65)
2500 lbs
P
N 320
320 (12.60)
Dimensions B and C for external cage models (E33/E34/E35/E36)
Flanged process connections
Flange size Flange rating Connection type
Dimensions
B C
1 1/2"
150 / 300 / 600 lbs Slip on - ANSI RF 180 (7.09) 268 (10.55)
600 lbs Weldneck - ANSI RJ 180 (7.09) 268 (10.55)
900 lbs Weldneck - ANSI RJ 195 (7.68) 281 (11.06)
1500 lbs Weldneck - ANSI RJ 186 (7.32) 281 (11.06)
2500 lbs Weldneck - ANSI RJ 229 (9.02) 313 (12.32)
2"
150 / 300 / 600 lbs Slip on - ANSI RF 185 (7.28) 273 (10.75)
600 lbs Weldneck - ANSI RJ 185 (7.28) 273 (10.75)
900 lbs Weldneck - ANSI RJ 215 (8.46) 302 (11.89)
1500 lbs Weldneck - ANSI RJ 212 (8.35) 302 (11.89)
2500 lbs Weldneck - ANSI RJ 250 (9.84) 329 (12.95)
DN 40
PN 16 / PN 25 / PN 40 EN 1092-1 Type B1 180 (7.09) 268 (10.55)
PN 63 / PN 100 EN 1092-1 Type B2 200 (7.87) 288 (11.34)
PN 160 EN 1092-1 Type B2 200 (7.87) consult factory
PN 250 EN 1092-1 Type B2 consult factory consult factory
PN 320 EN 1092-1 Type B2 consult factory consult factory
DN 50
PN 16 EN 1092-1 Type B1 185 (7.28) 273 (10.75)
PN 25 / 40 EN 1092-1 Type B1 188 (7.40) 276 (10.87)
PN 63 EN 1092-1 Type B2 202 (7.95) 293 (11.54)
PN 100 EN 1092-1 Type B2 208 (8.19) 299 (11.77)
PN 160 EN 1092-1 Type B2 215 (8.46) consult factory
PN 250 EN 1092-1 Type B2 consult factory consult factory
PN 320 EN 1092-1 Type B2 consult factory consult factory
Threaded / Socket weld process connections
Size Cage rating Connection type
Dimensions
B C
1 1/2"
150 / 300 / 600 / 900 lbs NPT/SW 81 (3.19)
Not
Applicable
1500 lbs NPT/SW 89 (3.50)
2500 lbs NPT/SW 102 (4.02)
2"
150 / 300 / 600 / 900 lbs NPT/SW 84 (3.31)
1500 lbs NPT/SW 98 (3.86)
2500 lbs NPT/SW 111 (4.37)
