2.4.2 Angle Symbols
Once the adjustment of the inclination sensor has been completed, an angle symbol
appears in the info bar to indicate the adjusted/active inclination axes.
Overview of symbols:
Both axes adjusted/active,
headlight tester ready for op-
eration
Z-axis active, headlight tester
ready for operation
Both axes active, inclination of
Z- and X-axis too large, no
measurement possible
Z-axis active, inclination too
large, no measurement possi-
ble
Both axes active, inclination of
X-axis too large, no measure-
ment possible
X-axis active, headlight tester
ready for operation
Both axes active, inclination of
Z-axis too large, no measure-
ment possible
X-axis active, inclination too
large, no measurement possi-
ble
